PPA5500 [Gen3]
1, 2 or 3 Phase DC to 2MHz Precision Power Analyzers
Building on the PPA4500 design, the PPA5500 power analyzer series adds low level measurement sensitivity plus enhanced computing power, to achieve market leading dynamic range and superior measurement accuracy in the most demanding power applications.Target applications include full compliance IEC61000 Harmonic and Flicker testing or power transformer loss measurements. Leading performance in these applications is achieved with a combination of unmatched magnitude and phase accuracy in the presence of real-world noise or distortion, with sample window synchronisation unique to the PPA and accredited calibration unmatched in its field.
Key Features
- Full rack wide 3U high
- DC and 10mHz to 2MHz
- 0.02% nominal power accuracy
- 5 milli degree phase accuracy
- Higher processing power
- Wider dynamic range
Applications
- Research, Development and Test
- Motor / Inverters
- Magnetics design and test
- Component loss analysis
