PSM1735
DC and 10μHz to 35MHz Frequency Response Analyzer
With a proprietary design that incorporates both direct digital analysis and heterodyning techniques, the PSM1735 provides a broad range of measurement functions over an exceptionally wide frequency range. Typical applications for this product include switched mode power supply feedback loop analysis, filter test and design, LVDT testing, sweep frequency response analysis of wound components and much more. As with other N4L products, PSM1735 utilises DSP and FPGA technology to optimise the use of its analogue hardware, providing speed and measurement flexibility without compromise on the performance of each measurement function. 0.01dB gain and 0.02° phase accuracy and a frequency range of 10uHz to 35MHz with ground referenced or differential inputs make the PSM1735 the frequency response analyzer of choice for many design and test engineers.Key Features
- DC and 10uHz to 35MHz
- 2x Single ended grounded & balanced differential inputs
- 1mV to 10Vpk input ranges
- 0.01° Phase accuracy
- Ground referenced generator
Applications
- Control Loop Analysis
- RFI line filter design and test
- Amplifier frequency response
- Low level gain and phase response
- High voltage common mode with differential input configuration
